DIN VDE 0817 L-2yy (Z) Y Kf 40 Conductor de Cobre Trenzado Aislamiento de PE Cubierta de PVC Cable de Control Flexible Resistente a la Tensión para Minería

China DIN VDE 0817 L-2yy (Z) Y Kf 40 Conductor de Cobre Trenzado Aislamiento de PE Cubierta de PVC Cable de Control Flexible Resistente a la Tensión para Minería fabricante y proveedor

DIN VDE 0817 L-2yy (Z) Y Kf 40 Conductor de Cobre Trenzado Aislamiento de PE Cubierta de PVC Cable de Control Flexible Resistente a la Tensión para Minería image

Get Latest Price Request a quote

Product Details

No. de Modelo.

L-2YY(Z)Y KF 40

Corriente

DC y AC

Material de aislamiento

Goma

Material de la Funda

goma

Forma Material

Alambre redondo

Alambre Material del núcleo

Alambre de cobre desnudo

Certificación

ISO, CE, VDE

Marca

huadong

nombre del producto

mining control cable

tensión nominal

100/100V

estándar

din vde 0817

muestra

disponible

Paquete de Transporte

por tambor de madera

Especificación

en metros

Marca Comercial

huadong

Origen

China

Código del HS

8544492100

Capacidad de Producción

15 millones de km

Product Description

L-2YY(Z)Y KF 40 375V strain resistant control cable according to DIN VDE 0817

Application:

Strain resistant control and communication cables can be used as flexible control cable for the operation at conveyor belts in open cast mining

applications. The cables are suitable for flexible applications in temperatures up to -40°C. L-2YY(Z)Y KF 40 is not approved for continuous laying in the ground.
Electrical parameters:

Rated voltage 100/100V (<300/300V)

Maximum permissible operating voltage AC 0.375 kV

AC test voltage 1 kV

insulation resistance 5 MΩxkm

Conductor loop resistance at 20°C max. 77.8 Ω/km

max. operating capaci-tance 65 nF/km

Construction:

Conductor	Finely stranded copper conductor (class 5)
Insulation	Thermoplastistic compound (PE)
Core identification	1. Strain: Red-Yellow, 2. Strain: Blue-Green Quad: 1. Strain: Natural Color-Yellow, 2. Strain: Blue-Green
Core arrangement	1. Strain: Natural Color-Yellow, 2. Strain: Blue-Green Core arrangement Four cores stranded as Star Quad (Twisted-Quad). These quads are subsequently stranded as cable core arrangement.
Inner sheath	Thermoplastic compund (PVC)
Reinforcement	Braiding of steel wires between inner and outer sheath
Outer sheath	Thermoplastic compound (PVC), Color: Grey, Cold resitant

Technical parameter:

1.You are manufacturer or trader ?

We are a professional cable&wire manufacturer with more than 20 years experience.Our factory located in jiaozuo city,henan province,china.

2.How can I get the quotation of the products ?

Pls send inquiry to us,we will reply you within 12 hours.

3.What does your company do regarding quality control?

1) All raw materials we selected are the highest quality.

2) Professional and skillful workers care every details in handling the producing.

3) Quality control department is specially responsible for quality checking in each process.

4.Do you provide OEM project service?

Yes,OEM & ODM order is warmly welcomed.

Our technical engineers can give you the professional suggestions.

5.Can I get the sample?

Yes,pls send inquiry to us,then our sales manager will arrange the samples for you.

Nosotros somos China DIN VDE 0817 L-2yy (Z) Y Kf 40 Conductor de Cobre Trenzado Aislamiento de PE Cubierta de PVC Cable de Control Flexible Resistente a la Tensión para Minería fabricante y proveedor,Puede obtener más detalles con el correo electrónico, obtendrá un precio económico o un precio de fábrica.
